PoE Standards Explained: 802.3af, 802.3at, and 802.3bt — What Every AV Integrator Needs to Know
If you've ever spec'd a conference room scheduling display, a PoE-powered camera, or any network-attached AV device, you've encountered the three IEEE Power over Ethernet standards: 802.3af, 802.3at, and 802.3bt. They look similar on a spec sheet. They are not the same in the field. Getting the wrong one means a device that won't power up, a switch port that trips, or a retrofit that costs more than it should. This guide breaks down what each standard actually delivers, where each one belongs in a real AV deployment, and how to pick the right hardware the first time.
What Is PoE and Why It Matters for Enterprise AV
Power over Ethernet (PoE) delivers electrical power alongside network data through a single Cat5e or Cat6 cable. For AV integrators, that means one cable run instead of two — no separate power outlet required, no low-voltage electrician on the punch list, and no wall wart taped to the back of a display.
In enterprise deployments, PoE is the standard delivery method for conference room scheduling displays, PTZ cameras, intercoms, access control readers, and increasingly, high-performance computing endpoints. The ability to power devices from the network closet also means centralized power management: UPS backup at the switch, remote power cycling, and clean power that isn't sourced from a shared office circuit.
But PoE is not one-size-fits-all. The standard has evolved across three generations, and the differences in available wattage are significant enough to determine whether a device works at all.
IEEE 802.3af — The Baseline Standard (Up to 15.4W)
802.3af is the original PoE standard, ratified in 2003. It delivers up to 15.4W at the source, with approximately 12.95W available at the powered device (PD) after cable loss.
For its era, that was sufficient. VoIP phones, basic IP cameras, and low-power sensors all fall within the 802.3af envelope. In modern AV deployments, 802.3af is best suited for:
- Room scheduling tablets running at reduced brightness
- Desk booking displays with simple UI and minimal processing
- Presence sensors and occupancy detectors
- Low-draw IoT endpoints
If your device draws less than 13W and you don't need USB-C Power Delivery headroom, 802.3af is adequate — and lower-cost infrastructure supports it universally.
PowerBx's entry-level POE-GIG-DVR PoE-to-USB-C adapter is designed for exactly this tier: 802.3af input, fixed 5V/2A USB-C output, Gigabit-capable data pass-through, and a price point that makes it easy to deploy at scale. Starting at $65.
IEEE 802.3at (PoE+) — 30W for More Demanding Devices
802.3at, ratified in 2009 and commonly called PoE+, doubles the available power to 30W at the source, with up to 25.5W at the device. It's backward compatible with 802.3af equipment.
PoE+ opened the door to a broader category of powered devices: higher-resolution cameras, more powerful access control panels, displays with active processing, and multi-function room peripherals. In today's AV environments, 802.3at is frequently the right baseline for:
- 10" conference room scheduling displays with active compute
- Video conferencing endpoints with integrated speakers
- PTZ cameras with optical zoom
- Network-attached digital signage players
The PowerBx POE-GIG multi-voltage USB-C PoE adapter targets this tier with full 802.3af/at compliance and self-adapting USB-C Power Delivery output: 5V, 9V, 12V, or 15V — up to 3A depending on device negotiation. Gigabit data pass-through, 1500V isolation, and a compact 80×35×25mm form factor make it the right adapter for integrators who need reliable performance without over-engineering the power budget. Starting at $149.
IEEE 802.3bt (PoE++) — 60W and 90W for High-Power Applications
802.3bt, finalized in 2018, is the current ceiling of the PoE standard. It defines two sub-types:
- Type 3 (802.3bt): Up to 60W at the source / ~51W at the device
- Type 4 (802.3bt Class 8): Up to 90W at the source / ~71.3W at the device
802.3bt uses all four cable pairs for power delivery (vs. two pairs for 802.3af/at), which is why it requires Cat5e or better and benefits from Cat6 in longer runs. It is backward compatible with both prior standards.
At this power tier, the application set expands significantly: high-performance pan-tilt-zoom cameras, thin client workstations, powered USB hubs, LED lighting panels, and large-format conference room displays. 802.3bt is increasingly specified in new enterprise builds where the goal is to eliminate AC outlets from the device layer entirely.
The PowerBx POE-90W high-power PoE injector is built to the full 802.3bt Type 4 / Class 8 spec. It accepts AC 100–240V input, passes Gigabit data, supports cable runs up to 100m on Cat5/5e/6 (120m on copper Cat6), and is rated for -20°C to +60°C — industrial-grade performance suitable for telecom closets, unconditioned utility spaces, and demanding AV infrastructure. Starting at $99.
Choosing the Right PoE Standard — A Decision Framework for Integrators
The right PoE tier comes down to three questions:
- What does the device actually draw? Check the manufacturer's PoE class specification, not just the rated wattage. Budget 10–15% headroom above the rated draw for startup surge and thermal variation.
- What does your infrastructure support? Most enterprise switches deployed in the last five years support 802.3at. 802.3bt requires a newer switch with 4-pair PoE support. Injectors like the POE-90W let you retrofit high-power devices onto legacy infrastructure without replacing the switch.
- Is USB-C Power Delivery in the chain? Modern scheduling displays, tablets, and thin clients increasingly use USB-C. Not all PoE-to-USB-C adapters support PD negotiation. The POE-GIG auto-negotiates PD voltage — critical for devices that won't charge on a fixed 5V feed.
When in doubt: size up. The incremental cost difference between an 802.3af and 802.3at adapter is small. The cost of a return trip to a site because the display won't power on is not.
The PowerBx PoE Product Line
PowerBx manufactures and stocks PoE adapters across all three standards. Each product is designed for real AV deployments — not consumer electronics. Gigabit data pass-through, USB-C output, and enterprise-grade build quality are standard across the line.
POE-GIG-DVR — Entry Level (802.3af), from $65
- PoE Standard: IEEE 802.3af | Input: DC 37–57V
- Output: 5V fixed / 2A (10W) | Connector: USB-C
- Data: 10/100 Mbps
- Best for: Low-power scheduling panels, iPad displays, fixed 5V USB-C devices
POE-GIG — Mid Tier (802.3af/at, Auto-PD), from $149
- PoE Standard: IEEE 802.3af/at | Input: 44–57V DC
- Output: 5V/3A, 9V/3A, 12V/3A, 15V/2A — self-adapting USB-C PD
- Data: Gigabit (10/100/1000 Mbps) | Isolation: 1500V
- Dimensions: 80×35×25mm | Cable: 225mm
- Best for: 10" scheduling displays, modern tablets, any USB-C PD device
POE-90W — High Power (802.3bt Type 4), from $99
- PoE Standard: IEEE 802.3bt (Type 4, Class 8) / 802.3at / 802.3af
- Max PoE Output: 90W | Power Input: AC 100–240V, 50/60Hz
- Data: Gigabit (10/100/1000 Mbps) | Operating Temp: -20°C to +60°C
- Best for: High-power AV endpoints, telecom closets, unconditioned spaces
Custom PoE Power Solutions
Not every deployment fits a standard configuration. PowerBx accepts custom product requests for unique power requirements — different voltage profiles, form factors, or environmental specs. Our team comes from the low-voltage and systems integration world, which means we understand what integrators actually need on a job site, not just what looks good in a catalog.
If you have a power requirement that doesn't fit the standard line, reach out to discuss a custom solution. We work through the spec with you directly.
Q4 2026: PowerBx Expands Into High-Density Battery Packs
PoE is one piece of the power infrastructure puzzle — but not every deployment has Ethernet. For robotics, UAVs, portable electronics, and mission-critical applications where wired infrastructure isn't an option, we're announcing a new product line.
We're excited to introduce the PowerBx High-Density Battery Pack Line — compact, lightweight battery packs built with advanced silicon-anode lithium-ion technology, delivering exceptional energy density and high power output in a compact footprint. Designed for portable electronics, robotics, UAVs, and mission-critical applications where weight, size, and peak power output all matter.
PowerBx High-Density Battery Pack Configurations
Each configuration increases voltage, stored energy, and available power while maintaining a consistent 11.05 Ah capacity, enabling scalable power solutions across a wide range of applications.
-
2-Cell Pack: 6.8V, 11.05Ah, 75Wh
Up to 367W continuous, 588W peak | Ideal for portable electronics, lightweight robotics, and IoT applications | Compact form factor minimizes weight without sacrificing output capacity -
3-Cell Pack: 10.2V, 11.05Ah, 113Wh
Up to 551W continuous, 881W peak | Balanced voltage and power for mid-range drones, electric hand tools, and portable power stations | Preferred for mission-critical field deployments requiring sustained high-power output -
4-Cell Pack: 13.6V, 11.05Ah, 150Wh
Up to 734W continuous, 1,175W peak | Maximum energy density and peak power for heavy-duty industrial applications, large UAVs, and extended-duration missions | Supports advanced robotics and autonomous systems requiring sustained power under demanding conditions
Technology Advantages
Silicon-Anode Lithium-Ion Technology: Advanced silicon anodes provide superior energy density compared to traditional graphite-based cells. This translates to more power in a smaller, lighter package — critical for applications where weight and space constraints drive system design.
Scalable Configurations: The 2-cell, 3-cell, and 4-cell lineup enables you to spec the exact power tier needed for your application. No oversizing, no wasted capacity — each configuration is purpose-built for its intended use case.
High Peak Power Output: Peak power ratings (588W, 881W, and 1,175W respectively) enable brief high-draw scenarios — drone takeoff, tool startup transients, emergency system activation — while maintaining stable continuous power delivery for sustained operation.
Applications
The PowerBx High-Density Battery Pack Line is engineered for:
- Robotics: Mobile robots, industrial automation systems, and inspection drones requiring sustained high power in compact deployments
- Unmanned Aerial Vehicles (UAVs): Consumer and industrial drones, aerial surveys, and long-range autonomous systems where battery weight directly impacts flight time
- Portable Electronics: Field laptops, portable workstations, emergency backup power systems, and outdoor monitoring equipment
- Mission-Critical Applications: Emergency response systems, off-grid infrastructure, and deployments where reliability and power availability are non-negotiable
Availability and Pricing
The PowerBx High-Density Battery Pack Line will be available in Q4 2026. Pricing will be announced in the coming weeks. If you have a specific power requirement or application in mind, contact us now — we're taking early inquiries and can work through custom configurations for your application.
Power Your Next Deployment Right
Whether you're spec'ing a single conference room scheduling panel or deploying PoE infrastructure across a multi-site enterprise campus, PowerBx has the hardware to match your power tier. Browse the full PoE adapter line or get in touch for project-specific recommendations.
